マルチモードファイバ出力LD – HHLパッケージは、半導体レーザのピグテイルにマルチモードファイバ(MMF)を採用したHHLパッケージのLDです。445nmから1550nmまで各種波長帯のLDがございます。同一波長で各種パワーのLDをご用意しておりますので用途に合わせて最適な機種をお選びいただけます。
→半導体レーザとは

marchfiber

波長
(nm)
型番 出力
(W)
ファイバコア径
(μm)
パッケージ コネクタ
445 3 300 P2 SMA905/FC
5 400 P2 SMA905/FC
10 600 P2 SMA905/FC
532 0.1 50 9-Pin SMA905/FC
0.2 50 9-Pin SMA905/FC
0.5 50 9-Pin SMA905/FC
635 0.35 105 2-Pin/4-Pin SMA905/FC
1 <300 P2 SMA905/FC
2 <400 P2 SMA905/ST/FC
2.5 400 P2 SMA905/ST/FC
650 0.35 105 2-Pin/4-Pin SMA905/FC
0.7 105 2-Pin/4-Pin SMA905/FC
0.7 105 9-Pin SMA905/ST/FC
1 <300 P2 SMA905/FC
2 <300 P2 SMA905/ST/FC
5 400 P2 SMA905/FC
660 0.7 105 2-Pin/4-Pin SMA905/FC
0.7 105 9-Pin SMA905/ST/FC
2 <300 P2 SMA905/FC
5 <400 P2 SMA905/FC
770 1.5 200 2-Pin/4-Pin SMA905/ST/FC
4.5 <300 P2 SMA905/ST/FC
10 <400 P2 SMA905/ST/FC
785 0.7 – 0.8 105 2-Pin/4-Pin SMA905/ST/FC
1 60 4-Pin/9-Pin SMA905/ST/FC
1.5 200 2-Pin/4-Pin SMA905/ST/FC
2 200 4-Pin/9-Pin SMA905/ST/FC
4.5 <300 P2 SMA905/ST/FC
10 <400 P2 SMA905/ST/FC
792 2 – 2.2 200 4-Pin SMA905/ST/FC
2 – 2.2 20 9-Pin SMA905/ST/FC
808 3 105 2-Pin FC
3.5 105 9-Pin FC
4 62.5 2-Pin FC
5 200 2-Pin FC
4 – 5 200 9-Pin FC
7 105 2-Pin FC
7 200 9-Pin FC
8 200 2-Pin FC
8 400 9-Pin FC
12 200 2-Pin FC
12 300 P2 FC
14 <300 P2 FC
20 200 2-Pin FC
20 <300 P2 FC
28 <400 P2 FC
830 1 60 2-Pin/4-Pin SMA905/ST/FC/SC
1.5 60 2-Pin/4-Pin SMA905/ST/FC/SC
2 – 2.5 200 4-Pin/9-Pin SMA905/ST/FC
6 – 7 <300 P2 SMA905/ST/FC
12 375 P2 SMA905/ST/FC
15 375 P2 SMA905/ST/FC
850 1.5 105 4-Pin SMA905/ST/FC
1.5 105 9-Pin SMA905/ST/FC
2.5 – 3 <300 P2 SMA905/ST/FC
5 – 6 <400 P2 SMA905/ST/FC
880 2 200 4-Pin SMA905/ST/FC
2 200 9-Pin SMA905/ST/FC
3 105 2-Pin/4-Pin SMA905/ST/FC
12 300 P2 FC
15 375 P2 FC
915 5 105 2-Pin/4-Pin FC
8 105 2-Pin/4-Pin FC
15 <300 P2 FC
940 1.5 105 14-Pin SMA905/ST/FC
3 105 2-Pin FC
4 200 9-Pin SMA905/ST/FC
10 105 2-Pin FC
12 300 P2 FC
15 300 P2 FC
20 <300 P2 FC
30 <300 P2 FC
980 4 105 2-Pin/4-Pin FC
4 200 9-Pin SMA905/ST/FC
10 105 2-Pin/4-Pin FC
12 300 P2 FC
15 300 P2 SMA905/ST/FC
1064 1.5 200 2-Pin/4-Pin SMA905/ST/FC
2 200 2-Pin/4-Pin SMA905/ST/FC
2 200 9-Pin SMA905/ST/FC
3.5 – 4 200 4-Pin/9-Pin SMA905/ST/FC
3.5 – 4 200 9-Pin SMA905/ST/FC
10 <400 P2 SMA905/ST/FC
15 <400 p2 SMA905/ST/FC
1310 0.7 105 4-Pin SMA905/ST/FC
0.7 105 9-Pin SMA905/ST/FC
2 <300 P2 SMA905/ST/FC
5 <400 P2 SMA905/FC
1330 0.7 105 4-Pin SMA905/ST/FC
0.7 105 9-Pin SMA905/ST/FC
2 <300 P2 SMA905/FC
5 <400 P2 SMA905/FC
1450 0.35 200 4-Pin/9-Pin SMA905/ST/FC
1.2 – 1.5 105 4-Pin SMA905/ST/FC
1.2 – 1.5 105 9-Pin SMA905/ST/FC
3 105 2-Pin/4-Pin FC
12 300 P2 SMA905/FC
15 350 P2 SMA905/FC
1470 0.6 -0.65 200 4-Pin/9-Pin SMA905/FC
0.7 105 4-Pin SMA905/FC
0.7 105 9-Pin SMA905/FC
3 105 2-Pin/4-Pin FC
12 300 P2 SMA905/FC
15 350 P2 SMA905/FC
1530 1.2 – 1.5 105 4-Pin SMA905/ST/FC
1.2 – 1.5 105 9-Pin SMA905/ST/FC
10 <400 P2 SMA905/ST/FC
1550 0.6 – 0.65 200 4-Pin/9-Pin SMA905/ST/FC
0.6 – 0.65 200 9-Pin SMA905/ST/FC
1.2 – 1.5 105 4-Pin SMA905/ST/FC
1.2 – 1.5 105 9-Pin SMA905/ST/FC
10 <400 P2 SMA905/FC
メーカ Wavespectrum Laser.Inc.
